Dual-Control-Head Flexibility
A single transceiver can drive two IP67 control heads up to 10 m apart—perfect for fire-apparatus cab-and-pump-panel setups. Each head offers the same VGA 640 × 480 TFT, backlit keypad and soft-menu structure, so crews never re-learn the interface when they switch seats.

10 W High-Power Option
While most mobile rigs stop at 3 W, the MTM5200 delivers a full 10 W (40 dBm) in Class 2 mode. The extra 5 dB of link budget extends fringe coverage by 25 %, letting one site serve a county instead of a township—fewer towers, lower OPEX.

TEDS Data-Ready Hardware
The transceiver ships with 25 kHz and 50 kHz channel filters, 64-QAM modulator and USB 2.0 PEI. Activate TEDS through a software licence and enjoy up to 80 kb/s for fingerprint uploads, mug-shot push or SCADA telemetry—no hardware swap, no truck-roll.

Gateway & Repeater in One Box
Enable “DMO Repeater” in code-plug and the unit becomes a store-and-forward node between handhelds and the network. During basement rescues or mountain evacuations the vehicle itself is the base radio motorola crews depend on, keeping TMO/DMO gateways alive even if the site is lost.

Rugged Beyond Spec
IP54 dust-splash on the transceiver, IP67 on the control head, MIL-STD 810 G for shock, vibration, salt-fog and solar radiation. Operating range –30 °C to +60 °C; storage –40 °C to +85 °C. The MTM5200 keeps running while competitive mobiles are back in the shop.

AES End-to-End Encryption
Hardware-based TEA1/TEA2/TEA3 plus SIM-scrubbed OTAR mean voice, SDS and packet data are protected from mic to ear. A stolen radio can be stunned or permanently killed over the air, ensuring your motorola mobile radio never becomes an enemy asset.
