• 1.Frequency:400-470mhz
• 2.Channels: 16
• 3.Output Power:5W
• 4.50 Groups CTCSS/104 Group DCS
• 5.DTMF function
• 6.VOX function
• 7.Adjust squelch level(0-9)
• 8.Timer-Out Timer(TOT)
• 9.Auto Scan Priority Channels
• 10.Busy Channle Lockout(BCLO)
• 11.Low battery alert
• 12.Battery Save
• 13.PC programming
• 14.Dimension: 54 x 122 x 33 mm( with KN
• B-29N)
• 15.Weight:360g(with battery)
• 16. Troop call/single call
• 17. Monitor function
• 18. Voice guide(English)
• 19. Squelch level setting function
• 20. Programmable by software
• 21. Up to 14 hours of work time

GENERAL		TK-3207
Frequency coverage (Varies according to version)		400-470MHz
Number of channels		16
Channel spacing (Varies according to version)		25 kHz/12.5 kHz
Frequency Stability		±2.5ppm (-30°C ~ +60°C)
Weight	Radio only	160g
	With KNB-29N	360g
Dimensions(W×H×D)		54 x 122 x 33 mm( with KNB-29N)
Channel Frequency Spread		38MHz
Operating Temperature Range		-30°C ~ +60°C -10°C ~ +60°C when KNB-29N in use
Antenna Impedance		50Ω
Operating Voltage		7.5 V DC ± 20 %

1 pcs Radio Body

1 pcs Charger Adapter & Base

1 pcs Battery

1 pcs Antenna

1 pcs Belt Clip

1 pcs User’s Manual
