TYT MD-380 1000 Channels DMR Digital Walkie Talkie UHF 400-480MHZ 5 Watts Long Range Two way Radio
Technical parameters
|
Item number |
MD-380 |
|
General |
|
|
Frequency Range |
400-480MHz |
|
Channel No. |
1000 |
|
Antenna impedance |
50 |
|
Antenna |
High and gain |
|
Operating Voltage |
7.5 vDC |
|
Operating Temperature |
-30°C~+60°C |
|
Dimension(W x H x D) |
128x61x38mm |
|
Battery |
2000mAh Li-ion |
|
Transmitter |
|
|
Output power |
>5W(H) >1W(L) |
|
Vocoder type |
TDMA |
|
Frequency Stability |
± 1.0 PPM |
|
Adjacent channel power |
<-60dB |
|
Spurious Radiation |
Antenna:9KHz-1GHz ,< -36dBm 1GHz-12.75GHz ,<-30dBm |
|
Hum and noise |
-40dB 12.5KHz |
|
4 FSK Digital Mode |
12.5KHz(data only):7k60FXD 12.5KHz(data+voice)7k60FXE |
|
Receiver |
|
|
Digital sensitivity |
0.3uV/-117.4dBm(BER 5%) 0.22uV/-100dBm(BER 1%) |
|
Audio distortion |
3%(TYPE) |
|
Audio power |
1W |
|
Autio response |
=1dB-3dB |
|
Adjacent Channel Selectivity |
Tia603C:65dB,ETSI:60dB |
|
Spurious |
Tia603C:75dB,ETSI:70dB |
|
Co Channel rejection |
>-12 dB |
