TYT TH-UV8000D Handheld Transceiver 10W Walkie Talkie VHF UHF Ultra-high 3600mAh Cross-Band Repeater Function Radio
Main feature:
16 channels
Programming protection
VOX
CTCSS/DCS
Cross band function
Chinese and English voice prompt
Battery saving function
Hi/low power selective
Scan
COMP
Wide/ Narrow bandwidth selective
End-tone elimination
Emergency alert
Power protection
High/low voltage TX prohition
Low battery prompt
General |
|
Frequency range |
VHF:136~174MHZ
|
Frequency Stability |
±2.5PPm |
Operating voltage |
DC 7.2V (Rechargeable Li-ion battery) |
Channel NO. |
128 |
Antenna impedance |
50 ohm |
Mode of operation |
Simplex or semi-duplex |
Battery capacity |
3600mAh |
Color |
Black |
Dimension(Exclude antenna) |
13x6x3.5cm |
Weight |
291g |
Receiver |
|
RF Sensitivity |
-122dBm(12dB SINAD) |
Audio power |
>0.5W |
Audio distortion |
<10% |
Blocking |
>=85dB |
Intermediation |
>=60dB, >=55dB |
Selectivity |
>=65dB, >=60dB |
Spurious rejection |
>=65dB |
Transmitter |
|
Output power |
=5W |
Modulation mode |
F3E |
Maximum deviation |
<5KHz/<2.5KHz |
Adjacent Ch. power |
<=-65dB/ <=-60dB |
Spurious radiation |
<7µW |
Pre-emphasis characteristics |
6dB |
Current |
<=2.8A(10W),<=1.8A(5W) |
CTCSS/DCS deviation |
0.55KHz±20.15KHz, 0.4KHz±20.1KHz |
Intermediation sensitivity |
8~12mV |
Intermediation distortion |
<5% |
